CX5Z-A2B2C5-70-8.0D18进口晶体,CX5石英晶体谐振器，美国进口晶振，卡迪纳尔SMD晶振，编码：CX5Z-A2B2C5-70-8.0D18，型号：CX5系列晶振，工作温度：-40°C ~ 85°C，精度：±20ppm，尺寸：7.2*5.2mm，频率：8 MHz，负载电容：18pF，晶体谐振器，无源晶体，石英晶振，微型薄型表面贴装晶体， 封装是自动化表面贴装的理想选择组装和回流实践，带卷包装，AT切割水晶，被广泛应用于蓝牙，无线局域网，物联网，GPS，军事设备，无线电话。
CX5Z-A2B2C5-70-8.0D18进口晶体,CX5石英晶体谐振器，参数表
| 编码 | CX5Z-A2B2C5-70-8.0D18 |
| 品牌 | Cardinal晶振 |
| 型号 | CX5 |
| 频率 | 8 MHz |
| 精度 | ±20ppm |
| 负载电容 | 18pF |
| 工作温度 |
-40°C ~ 85°C |
| Mfr Part # |
卡迪纳尔SMD晶振 |
Series | Frequency | Frequency Tolerance | Load Capacitance |
| CX5Z-A2B2C5-70-8.0D18 | Cardinal Components Inc. | CX5 | 8 MHz | ±20ppm | 18pF |
| CX5Z-ARB2C5-70-7.3728D18 | Cardinal Components Inc. | CX5 | 7.3728 MHz | ±20ppm | 18pF |
| CX5Z-A5B2C5-40-24.0D18 | Cardinal Components Inc. | CX5 | 24 MHz | ±20ppm | 18pF |
| CX5Z-A2B2C5-40-12.0D18 | Cardinal Components Inc. | CX5 | 12 MHz | ±20ppm | 18pF |
| CX5Z-A5B2C5-40-12.0D18 | Cardinal Components Inc. | CX5 | 12 MHz | ±20ppm | 18pF |
| CX5Z-A5B2C5-40-10.0D18 | Cardinal Components Inc. | CX5 | 10 MHz | ±20ppm | 18pF |
| CX5Z-A2B2C5-40-10.0D18 | Cardinal Components Inc. | CX5 | 10 MHz | ±20ppm | 18pF |
| CX5Z-A1B2C5-40-24.0D18 | Cardinal Components Inc. | CX5 | 24 MHz | ±20ppm | 18pF |
| CX5Z-A5B2C5-40-24.576D18 | Cardinal Components Inc. | CX5 | 24.576 MHz | ±20ppm | 18pF |
| CX5Z-A5B2C5-70-7.37280D18 | Cardinal Components Inc. | CX5 | 7.3728 MHz | ±20ppm | 18pF |
| CX5Z-A2B2C5-40-25D18 | Cardinal Components Inc. | CX5 | 25 MHz | ±20ppm | 18pF |
| CX5Z-A5B2C5-50-16.0D18 | Cardinal Components Inc. | CX5 | 16 MHz | ±20ppm | 18pF |
| CX5Z-A5B2C5-40-25D18 | Cardinal Components Inc. | CX5 | 25 MHz | ±20ppm | 18pF |
| CX5Z-A0B2C5-50-16.0D18 | Cardinal Components Inc. | CX5 | 16 MHz | ±20ppm | 18pF |
| CX5Z-A5B2C5-40-27.0D18 | Cardinal Components Inc. | CX5 | 27 MHz | ±20ppm | 18pF |
| CX5Z-A5B2C5-70-8.0D18 | Cardinal Components Inc. | CX5 | 8 MHz | ±20ppm | 18pF |
