高频低抖动时钟振荡器531AC200M000DG专用于时钟和数据恢复
Silicon晶振Si531 XO利用天空解决方案的先进DSPLL®电路提供一个高频低抖动时钟晶体振荡器。Si531晶振小体积7.0x5.0mm六脚贴片晶振，可提供从10到945MHz的任意速率输出频率，并选择频率到1400MHz。与传统的XO不同，每个输出频率都需要一个不同的晶体，使用一个固定的晶体来提供一个大范围的输出频率。这种有源晶振基于集成电路的方法允许晶体谐振器提供特殊的频率稳定性和可靠性。此外，DSPLL时钟合成提供了优越的电源噪声抑制，简化了在通信系统中通常发现的噪声环境中产生低抖动时钟的任务。基于Si531 IC的XO可在工厂中进行配置，可用于各种用户规格，包括频率、电源电压、输出格式和温度稳定性。特定的配置在装运时被工厂编程，从而消除了与定制振荡器相关的长交货时间。高频低抖动时钟振荡器531AC200M000DG专用于时钟和数据恢复
| 原厂代码 | 品牌 | 型号 | 频率 | 电压 | 频率稳定度 | 包装/封装 |
| 531BB125M000DG | Silicon晶振 | Si531 | 125MHz | 3.3V | ±20ppm | 6-SMD, No Lead |
| 531FB200M000DG | Silicon晶振 | Si531 | 200MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
| 531FC250M000DG | Silicon晶振 | Si531 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FB125M000DG | Silicon晶振 | Si531 | 125MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
| 531BC000110DG | Silicon晶振 | Si531 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC200M000DG | Silicon晶振 | Si531 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC250M000DG | Silicon晶振 | Si531 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC125M000DG | Silicon晶振 | Si531 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531FB106M250DG | Silicon晶振 | Si531 | 106.25MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
| 531AC156M250DG | Silicon晶振 | Si531 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC200M000DG | Silicon晶振 | Si531 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC148M500DG | Silicon晶振 | Si531 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC156M250DG | Silicon晶振 | Si531 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC125M000DG | Silicon晶振 | Si531 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531FC125M000DG | Silicon晶振 | Si531 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC156M250DG | Silicon晶振 | Si531 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC148M500DG | Silicon晶振 | Si531 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC155M520DG | Silicon晶振 | Si531 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC155M520DG | Silicon晶振 | Si531 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531FC200M000DG | Silicon晶振 | Si531 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC622M080DG | Silicon晶振 | Si531 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC312M500DG | Silicon晶振 | Si531 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC106M250DG | Silicon晶振 | Si531 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC106M250DG | Silicon晶振 | Si531 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531BC187M500DG | Silicon晶振 | Si531 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC155M520DG | Silicon晶振 | Si531 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC187M500DG | Silicon晶振 | Si531 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC187M500DG | Silicon晶振 | Si531 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC000110DG | Silicon晶振 | Si531 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC148M500DG | Silicon晶振 | Si531 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC155M520DG | Silicon晶振 | Si531 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC156M250DG | Silicon晶振 | Si531 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC311M040DG | Silicon晶振 | Si531 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC311M040DG | Silicon晶振 | Si531 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC311M040DG | Silicon晶振 | Si531 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC622M080DG | Silicon晶振 | Si531 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC622M080DG | Silicon晶振 | Si531 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC311M040DG | Silicon晶振 | Si531 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531BC622M080DG | Silicon晶振 | Si531 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531FC312M500DG | Silicon晶振 | Si531 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC312M500DG | Silicon晶振 | Si531 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC250M000DG | Silicon晶振 | Si531 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC250M000DG | Silicon晶振 | Si531 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531BC312M500DG | Silicon晶振 | Si531 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AA156M250DG | Silicon晶振 | Si531 | 156.25MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
| 531BC106M250DG | Silicon晶振 | Si531 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC125M000DG | Silicon晶振 | Si531 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC106M250DG | Silicon晶振 | Si531 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC187M500DG | Silicon晶振 | Si531 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC000110DG | Silicon晶振 | Si531 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC200M000DG | Silicon晶振 | Si531 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC000110DG | Silicon晶振 | Si531 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC148M500DG | Silicon晶振 | Si531 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC125M000DGR | Silicon晶振 | Si531 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC125M000DGR | Silicon晶振 | Si531 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC125M000DGR | Silicon晶振 | Si531 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC125M000DGR | Silicon晶振 | Si531 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC106M250DGR | Silicon晶振 | Si531 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC106M250DGR | Silicon晶振 | Si531 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC106M250DGR | Silicon晶振 | Si531 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC106M250DGR | Silicon晶振 | Si531 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC25M0000DGR | Silicon晶振 | Si531 | 25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC155M520DGR | Silicon晶振 | Si531 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC156M250DGR | Silicon晶振 | Si531 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC155M520DGR | Silicon晶振 | Si531 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC156M250DGR | Silicon晶振 | Si531 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC155M520DGR | Silicon晶振 | Si531 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC156M250DGR | Silicon晶振 | Si531 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC155M520DGR | Silicon晶振 | Si531 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC156M250DGR | Silicon晶振 | Si531 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC187M500DGR | Silicon晶振 | Si531 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC187M500DGR | Silicon晶振 | Si531 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC187M500DGR | Silicon晶振 | Si531 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC187M500DGR | Silicon晶振 | Si531 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC000110DGR | Silicon晶振 | Si531 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC148M500DGR | Silicon晶振 | Si531 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC200M000DGR | 贴片晶振 | Si531 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC000110DGR | Silicon晶振 | Si531 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC148M500DGR | Silicon晶振 | Si531 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC200M000DGR | Silicon晶振 | Si531 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC000110DGR | Silicon晶振 | Si531 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC148M500DGR | Silicon晶振 | Si531 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC200M000DGR | Silicon晶振 | Si531 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC000110DGR | Silicon晶振 | Si531 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC148M500DGR | Silicon晶振 | Si531 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC200M000DGR | Silicon晶振 | Si531 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC312M500DGR | Silicon晶振 | Si531 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC312M500DGR | Silicon晶振 | Si531 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC312M500DGR | Silicon晶振 | Si531 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC312M500DGR | Silicon晶振 | Si531 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AC250M000DGR | Silicon晶振 | Si531 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC311M040DGR | Silicon晶振 | Si531 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531AC622M080DGR | Silicon晶振 | Si531 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC250M000DGR | Silicon晶振 | Si531 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC311M040DGR | Silicon晶振 | Si531 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531BC622M080DGR | Silicon晶振 | Si531 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 531EC250M000DGR | Silicon晶振 | Si531 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC311M040DGR | Silicon晶振 | Si531 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531EC622M080DGR | Silicon晶振 | Si531 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC250M000DGR | Silicon晶振 | Si531 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC311M040DGR | Silicon晶振 | Si531 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531FC622M080DGR | Silicon晶振 | Si531 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 531AA640M000BG | Silicon晶振 | Si531 | 640MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
Si531晶振特征：
可与任意速率的输出频率从10 MHz到945MHz和选择频率到1.4 GHz
第三代DSPLL®具有优越的抖动性能
比基于saw的振荡器好3倍的频率稳定性
内部固定的晶体频率确保了高可靠性和低老化
可用的CMOS、LVPECL、LVDS和CML输出石英晶体振荡器
3.3、2.5和1.8 V的供应选项
工业标准7.0x5.0mm封装和针形管
无铅/符合RoHS标准
应用于：超声波，网络系统，SD/高清视频，测试和测量，时钟和数据恢复，FPGA/ASIC时钟生成
